Reusable AXI-stream verification IPs in SystemVerilog

AXI Stream is my favorite protocol for custom designs. It’s dead simple (just tvalid and tready), yet can be made extremely performant and flexible. There are also several open source DMAs to bridge full AXI and AXI Stream, allowing quick SoC deployment.

Before integrating a DMA, we need to verify our IP follows AXI Stream perfectly. Transaction level testbenches with randomized drivers and monitors are the way to go. Building this for every IP is pretty repetitive. I built this VIP to make it modular, clean, and highly reusable.

Features

• Configurable AXI-Stream Source and Sink blocks.
• Simple API (file_tb and nofile_tb examples provided).
• Queues-based abstraction: simply push or pop data arrays into the VIP and let it handle the bus signaling.
• Built-in randomization of valid/ready backpressure signals and s_last, s_keep assertions.
• Functions to easily load from or dump out to text/binary test vector files.

Technical Details

I have two SV modules: Sink and Source. I pass in SystemVerilog queues containing the packets to be driven, and a task runs an infinite loop pushing data synchronously to the clock. I injected parameterized probabilities for stalling the interface (randomized tvalid gaps, randomly de-asserting tready).

  task automatic axis_push_packet(input logic signed [WORD_W-1:0] packet [$]);
    int total_words = packet.size();
    int n_beats = `CEIL(total_words, WORDS_PER_BEAT);
    int i_words = 0;

    for (int ib=0; ib < n_beats; ib++) begin
      // Between beats: keep outputs deasserted in the next cycle
      s_valid_d = 0; s_last_d = 0; s_keep_d = '0; s_data_d = 'x;

      // Random wait to inject tvalid gaps (simulating partial starvation)
      while ($urandom_range(0,99) >= PROB_VALID) @(posedge clk);

      // Assign payload structure
      s_valid_d = 1;
      s_last_d  = (ib == n_beats-1);

      // ... payload assignment ...

      // Wait for handshake (AXI protocol)
      @(posedge clk);
      while (!s_ready) @(posedge clk);
    end
  endtask

Getting it to work without #1ps delays, on Verilator, Icarus and Xsim was a pain. But it was one-time, and now I re-use this everywhere.

Repo: GitHub - axis_vip
